High output and repeat accuracy: ± 5% and ±3%.
Preset torque and automatic shutoff when reaching the set torque. Single-chip intelligent torque control system with LCD display.With manual 2-speed gearbox, high/low speed can be shifted freely
Very suitable for continuous operation in production assembly and maintenance. Free connection of power handle and drive unit, could be rotated 360°.
Higher efficiency whether tightening or loosening bolts and nuts than hydraulic torque wrench. Portable and durable design, low noise, with overload protection.
After-sales service: 1 year guarantee period, life-long maintenance.
| Model # | Min torque(N.m) | Max torque(N.m) | Drive S （mm） | D（mm） | L（mm） | K（mm） | M（mm） | Weight（Kg） | Idle speed(rpm) |
|---|---|---|---|---|---|---|---|---|---|
| KSEW-08S | 100 | 800 | 3/4＂ | 65 | 420 | 205 | 145 | 5 | 30 |
| KSEW-16S | 200 | 1600 | １＂ | 74 | 460 | 205 | 195 | 6.5 | 12.2 |
| KSEW-28S | 400 | 2800 | 1＂ | 78.5 | 480 | 205 | 215 | 8.2 | 6.3 |
| KSEW-40S | 700 | 4200 | １1/2＂ | 88 | 500 | 205 | 235 | 9.5 | 5.1 |
| KSEW-60S | 1000 | 6000 | １1/2＂ | 113 | 529 | 205 | 264 | 14.9 | 2.6 |
| KSEW-80S | 1200 | 8000 | １1/2＂ | 120 | 539 | 205 | 274 | 16.8 | 1.8 |
| KSEW-100S | 2000 | 10000 | １1/2＂ | 128 | 555 | 205 | 290 | 18.3 | 1.5 |
| KSEW-120S | 3000 | 12000 | １1/2＂ | 128 | 555 | 205 | 290 | 18.5 | 1.5 |
Spartan make Electric Torque wrench (Angle Type)
The SE Hydraulic Torque Wrench is the industry’s most advanced limited clearance hydraulic bolting system. The slim design fits where other tools will not and the dual piston power head provides unparalleled speed and power.
| Model # | Min torque(N.m) | Max torque(N.m) | Drive s （mm） | D（mm） | L（mm） | H（mm） | Weight（Kg） | Idle speed(rpm) |
|---|---|---|---|---|---|---|---|---|
| KSEW-08A | 100 | 800 | 3/4＂ | 65 | 320 | 249 | 6.6 | 30 |
| KSEW-16A | 200 | 1600 | 1＂ | 74 | 320 | 297 | 8.1 | 12.2 |
| KSEW-28A | 400 | 2800 | １＂ | 78.5 | 320 | 317 | 9.8 | 6.3 |
| KSEW-40A | 700 | 4200 | １1/2＂ | 88 | 320 | 337 | 11.4 | 5.1 |
| KSEW-60A | 1000 | 6000 | １1/2＂ | 113 | 320 | 366 | 16.5 | 2.3 |
| KSEW-80A | 1200 | 8000 | １1/2＂ | 120 | 320 | 376 | 18.4 | 1.8 |
| KSEW-100A | 2000 | 10000 | １1/2＂ | 128 | 320 | 395 | 20 | 1.5 |
| KSEW-120A | 3000 | 12000 | １1/2＂ | 128 | 320 | 395 | 20.1 | 1.5 |
